The Motion of Free Fall
BlackBoard Notes



--- There are five separate sections; write them in this order: 5, 1, 4, 2, 3 (split remaining section evenly for 2 and 3) ---

======================= Photo - Click for a Larger Version =============================

blackboard image

======================= First Board Section - Write this second, and make it narrow! =============================

======================= Second Board Section - Split remaining board evenly for second and third sections =============================

  • Calculate y for each even numbered dot, as measured from the zeroth dot!
  • Time conversion: 40 dots = 1 sec

======================= Third Board Section =============================

t  (dots) yi (cm) yf (cm)   y = yf – yi (cm)
0

18

2

4

10.0









10.0

0.0

Note: Begin creating Excel graph after third data point is collected!!

======================= Fourth Board Section =============================



Polynomial
  • How does your measured acceleration (ao), compare with the expected acceleration (g = 980 cm/s2)?
    • Print to Lab_Physics_204




  • Analysis (Recall Excel exercise):
  •

    • Theory: y = yo + vot + ½aot2

    • Excel: y = Ax2 + Bx + C
    {Color code to see matchup, specifically A = ½ao }

    ======================= Fifth Board Section - Write this table first, then do the first board section =============================

    ao (cm/s2)
